ECTFE Coating (Halar)

ECTFE Coating, commonly known by the trade name Halar®, is a high-performance fluoropolymer coating designed for extreme corrosion, permeation, and chemical resistance. It is especially suited for environments where conventional epoxy, rubber lining, or even PTFE coatings may fail.

ECTFE coatings form a dense, non-porous, and highly adherent barrier on metal substrates such as Mild Steel (MS), Stainless Steel (SS), and aluminum, offering outstanding protection against strong acids, alkalis, solvents, oxidizing chemicals, and corrosive fumes. Due to its excellent barrier properties, ECTFE is widely used for internal and external coating of tanks, vessels, pipes, ducts, scrubbers, and process equipment.

Key Features & Benefits

Exceptional Chemical Resistance
Highly resistant to strong acids (HCl, H₂SO₄), alkalis, chlorinated chemicals, oxidizers, and aggressive solvents.
Excellent Permeation Resistance
Very low permeability to gases and liquids, making it ideal for chlorine, bromine, and corrosive vapor environments.
Wide Temperature Capability
Suitable for continuous service up to 150°C with excellent performance at low temperatures as well.
Non-Porous & Smooth Surface
Prevents chemical absorption, scaling, fouling, and contamination.
Superior Adhesion to Metal
Strong bonding to steel surfaces ensures long-term durability without peeling or blistering.
High Abrasion & Impact Resistance
Tough coating structure resists mechanical damage during operation and handling.
Excellent Weather & UV Resistance
Suitable for outdoor applications, marine environments, and coastal installations.
Long Service Life & Low Maintenance
Extends equipment life and significantly reduces maintenance and downtime.

Typical Coating Specifications

Coating Type: ECTFE (Halar®) Fluoropolymer
Application Method: Electrostatic powder coating & fusion bonding
Typical Thickness: 300 – 1000 microns (customizable)
Surface Preparation: Grit blasting (SA 2.5)
Finish: Smooth, pinhole-free, seamless

Applications

Chemical & Petrochemical Plants
Storage tanks, reactors, pipelines, scrubbers, and ducting handling aggressive chemicals.
Chlor-Alkali & Acid Handling Systems
Excellent resistance to chlorine gas, hydrochloric acid, sodium hypochlorite, and similar media.
Water & Wastewater Treatment
Equipment exposed to corrosive chemicals, disinfectants, and aggressive effluents.
Power Plants
Flue gas ducts, chimneys, scrubbers, and corrosion-prone structures.
Oil & Gas Industry
Coating of vessels, piping, and equipment exposed to corrosive process streams.
Pharmaceutical & Specialty Chemicals
High-purity, non-contaminating surfaces for sensitive chemical processes.
Marine & Coastal Installations
Protection against salt spray, humidity, and harsh atmospheric conditions.

Advantage	Benefit
Excellent chemical resistance	Performs in extreme environments
Low permeability	Prevents gas & chemical ingress
High build seamless coating	Long-term corrosion protection
UV & weather resistance	Ideal for outdoor use
Long service life	Reduced maintenance costs
